Advantages of vacuum drying oven:
The vacuum drying furnace is designed for drying heat-sensitive, easily decomposed, and easily oxidized materials, and is especially suitable for drying complex raw materials.
Features of vacuum drying oven:
1. The cuboid cavity can reach the maximum effective volume.
2. Storage, heating, testing and drying are all carried out in a vacuum environment and will not be oxidized.
3. The heating time is shortened by more than 50% compared with the traditional vacuum drying oven.
4. The inside of the oven can withstand high vacuum pressure without any deformation.
5. Compared with the traditional vacuum drying oven, the energy consumption is reduced to 20%.
After-sales service:
1. Provide targeted installation videos;
2. Under the premise of correct installation, regular maintenance and use, we guarantee a one-year warranty;
3. After the expiration of the warranty period, the products sold by our company enjoy lifetime warranty repairs, and we only charge the cost price for replacing the standard parts and seals of the product;
4. The technical staff puts forward reasonable suggestions according to the use of the product, and assists the customer to choose the appropriate model;
5. Provide 24-hour technical consultation response.
Grouped equipment:
Diaphragm Vacuum Pump
Rotary vane vacuum pump
FAQ:
What are the similarities between the vacuum drying oven and the blast drying oven?
All are drying equipment, which can remove the moisture in the material to make it meet the requirements for further processing.
What is the difference between a vacuum drying oven and a blast drying oven?
The drying principle is different. The blast drying box heats the material under normal pressure to vaporize and evaporate the water in the material, thereby removing the water. The vacuum drying oven is a technology for drying at low pressure and high temperature, which is especially suitable for dehydration treatment of heat-sensitive materials and expensive materials.
How to set the temperature of the vacuum drying oven?
In the heat resistance range of the material, the higher the temperature, the better.
Model | DZF-6010 |
Power Supply(V/Hz) | 220/50 |
Shell Material | Spray-paint Anti-corrosion |
Liner Material | 304 Stainless Steel |
Temp. Range(°C) | RT+10~200 |
Max. Vacuum Degree(Mpa) | 0.098 |
Temp. Stability(°C) | ±1.0 |
Temp. Analysis(°C) | 0.1 |
Working Temp.(°C) | +5~40 |
Input Power (W) | 400 |
Chamber Capacity (L) | 8 |
Inner Dimension (W*D*H,mm) | 200*200*200 |
Overall Dimension (W*D*H,mm) | 600*400*430 |
Shelves (Pcs) | 1 |
Time Range(min) | 1~9999 |
Optional Configuration | Explosion-proof |
